4x2xAWG 23/1 S/FTP LSZH SHF2 MUD Cat. 7

Application

For use in the maritime environment and for offshore units, where there is a demand for high data transmission rates. The cable can be used in fixed installations both indoors and outdoors. Optimised for IEEE 802.3at PoE+.

Construction

Conductor

Bare solid Cu (AWG 23)

Insulation

Cellular PO (Ø 1.38 mm)

Conductor color

TIA/EIA 568-B

Inner sheath

Ø 8.8 mm white FR-LSZH

Screen

Shielded pairs: aluminium/polyester foil, helically applied over the conductors, 100% coverage
Overall screen: tinned Cu braid, 55% coverage
Solid annealed Cu drainwire (0.41 mm)

Outer sheath

Black XL-HFFR, UV resistant, MUD resistant

Technical data

Working temperature

-40° C to +85° C

Bend radius

Min. bending radius 110 mm
Cold bend: acc. to UL 44, CSA C22.2 number 38-95

Technical comments

Frequency range: 1-600 MHz
Impedance: 100 Ohm
Transfer impedance: grade 1
Coupling attenuation: type 1
DC resistance: 73 Ohm/km
Max. resistance unbalance: 2%
Max. screen resistance: 20 Ohm/km ved 20° C
Capacitance unbalance: max 1,2 pF/m
Velocity of propagation: 78%
Propagation delay skew: max. 25 ns/100 m
Dielectric strength: 700 V/minut
Dielectric strength to shield: 700 V/minut
Insulation resistance (min.): 5 GOhm x km
Tensile strength: max. 130 N/mm2







DC resistance: <17 Ohm/100 m.
Mutual capacitance: 5,6 nF/100 m.
Capacitance unbalance: <230 pF/100 m.
Char. impendence (1...100 MHz): 100 Ohm ± 15 Ohm
Char. impendence (100...750 MHz): 100 Ohm ± 22 Ohm
Max tractive force: 110 N/mm2

Approvals

IEC 60092-359, IEC 61156, IEEE 802.3at (Poe+), ISO/IEC 11801, RoHS-2 2011/65/EU, NEK TS 606, IEC 60332-1, IEC 60332-3-22, IEC 60332-3, IEC 60332-3-24, IEC 60754-1/2, IEC 61034-1/2, UL 1581 VW-1, DNV, ABS, CE
Environmentally friendly
Fire retardant acc. to IEC 60332-3
Flame retardant acc. to IEC 60332-1
For permanent outdoor installation
For use on oil rigs
For use on ships
Halogen free
Low emission of corrosive gases acc. to IEC 60754
Low smoke emission during fire acc. to 61034
Max. working temp. +85° C
Min. working temperature -40° C
Mudresistance NEK TS 606
Outdoor use
UV-resistant
SKU EAN Dimension (mm2) Current Value (A) Winding Diameter (mm)* Weight (kg/km)*
100250152 5704403065998 4x2xAWG23 - D./Cut 11,0 178
* The values can have small deviations
